The MEC Mec Electronic 20 Code Smart Lock is designed for upgrading your existing door security with a modern, keyless solution. Ideal for front and back doors, this smart lock offers convenient access control with multiple user PIN codes and advanced features, making it suitable for residential and commercial applications.

This smart lock features a motorised deadbolt with adjustable length of 60mm or 70mm, providing flexible installation options. It supports up to 20 user PIN codes, including a master code, and includes an auto-lock function for enhanced security. The keypad is backlit for easy operation in low light conditions, and the lock is equipped with a scramble code feature to prevent code theft.

Constructed from durable zinc alloy and plastic, the lock is suitable for various door types including wood, anti-burglary, and steel doors with thicknesses from 35mm to 50mm. It operates on DC 6V power supplied by four AA batteries and features an emergency power option via micro USB. The lock has an IP54 rating, ensuring resistance to dust and water splashes, and can function effectively within temperatures ranging from -25 to 70 degrees Celsius.

Installation is straightforward, making it suitable for both front and back doors. The lock includes a state indicator to show lock status and an emergency cylinder for manual override if needed. It is supplied with one unit per package, ready for easy setup.

Key Features:

• Upgrade your door security: Motorised deadbolt with adjustable length


• Access control: Supports 20 user PIN codes and one master code


• Convenient operation: Auto lock, one-touch locking, and backlit keypad


• Enhanced security: Scramble code feature and emergency cylinder


• Durable construction: Zinc alloy and plastic materials with IP54 rating


• Flexible installation: Suitable for various door types and thicknesses

Specifications:

• Bolt Type: Deadbolt


• Auto Locking: Yes


• Emergency Cylinder: Yes


• Keypad Type: Push button with backlit


• Code Length: 6-12 digits


• Number of Codes: 1 master code and 49 user codes


• Working Voltage: DC 6V (4 x AA batteries required)


• Emergency Power: 5V Micro USB


• Temperature Range: -25 to 70 degrees Celsius


• Water Resistance: IP54


• Suitable Doors: Wood, anti-burglary, steel


• Door Thickness: 35 to 50mm

• Zinc Alloy
