Your games in a whole new light Unleash the future of gaming with the Valve Steam Deck OLED Handheld Gaming Console (1TB). Take your gaming experience to a new level with a groundbreaking HDR OLED display, extended battery life and faster downloads.
Features

• Steam Deck's HDR OLED display is designed from the ground up for gaming with striking contrast, brilliant clarity, and a larger picture.
• With Steam Deck OLED, we've overhauled the internals, making battery life longer and downloads faster
• 30-50% more battery life.
• Wifi 6E, offering increased bandwidth, lower latency and up to 3 times faster downloads.
• Thanks to a bigger fan and updated thermals, Steam Deck OLED runs cooler and weighs 30g, or ~5% lighter than the LCD model
• The touchscreen's responsiveness and fidelity is vastly improved. Haptics are higher fidelity and more consistent.
• All of the rear case screws are now Torx™ type, and internal components are now easier to access (for trained professionals)

General

• Updated APU to 6 nm for better efficiency
• Updated memory to 6400 MT/s, improving latency and power management
• Increased thermal module thickness and performance

Display

• Increased active area to 7.4" (from 7.0")
• Updated refresh rate to 90Hz (from 60Hz)
• Updated peak brightness to 1000 nits
• Updated touchscreen polling rate to 180Hz, improved latency and accuracy

WiFi/Bluetooth

• Updated WiFi / Bluetooth module
• Added support for WiFi 6E
• Added support for Bluetooth 5.3, supporting newer codecs such as aptX HD and aptX low-latency
• Added third antenna near the top of the device for better Bluetooth performance, including when docked
• Added support for wake from Bluetooth controllers

Audio

• Improved bass response for an overall flatter sound profile
• Added support for using onboard microphone array simultaneously with the 3.5mm headphones connector

Controls

• Adjusted analog stick top material and shape for increased grip and dust build-up resistance
• Adjusted analog stick post material to improve interaction feel with front cover and reduce wear
• Improved reliability of analog stick touch detection
• Improved responsiveness and tactility of shoulder buttons switch mechanism
• Adjusted D-pad snap ratio and diagonal interactions
• Redesigned trackpad for improved fidelity and edge detection
• Greatly improved trackpad haptics feel and precision

Power

• Improved battery capacity from 40Wh to 50Wh
• Improved battery chemistry for faster charging, from 20% to 80% in as little as 45 minutes
• Changed charging LED to WRGB
• Added support for waking up from initial unboxing by long-pressing power button instead of requiring AC power
• Adjusted power supply cable length from 1.5m to 2.5m
• Added logo to power supply

Frame

• Reduced total system weight to ~640g, or ~5% less than Steam Deck
• Rear cover screws now thread into metal
• Adjusted rear cover screw heads to Torx™, as well as other materials and geometry tweaks on the heads to reduce stripping risk
• Lowered number of screw types throughout system
• Reduced step count required for common repairs
• Improved bumper switch mechanism drop reliability
• Moved bumper switch to joystick board for easier repair
• Improved display repair/replacement to not require taking rear cover off

Software

• Greatly improved memory power management firmware
• Added preliminary support for open-source BIOS and EC firmware
• Improved resume time by roughly 30%.

Contents

• Steam Deck
• Carry Case

Specifications

• Processor: 6 nm AMD APU, CPU: Zen 2 4c/8t, 2.4-3.5GHz (up to 448 GFlops FP32), GPU: 8 RDNA 2 CUs, 1.6GHz (1.6 TFlops FP32), APU power: 4-15W
• RAM: 16 GB LPDDR5 on-board RAM (6400 MT/s quad 32-bit channels)
• Storage: Steam Deck 512GB NVMe SSD + high-speed microSD card
• Gamepad controls: A B X Y buttons, D-pad, L & R analog triggers, L & R bumpers, View & Menu buttons, 4 x assignable grip buttons
• Thumbsticks: 2 x full-size analog sticks with capacitive touch
• Haptics: HD haptics
• Trackpads:, 2 x 32.5mm square trackpads with haptic feedback. Pressure-sensitivity for configurable click strength
• Gyro: 6-Axis IMU
• Display: 7.4" 1280 x 800 x RGB HDR OLED with High performance touch
  • Maximum brightness: 1,000 nits peak brightness (HDR) 600 nits (SDR)
  • Contrast ratio: > 1,000,000 : 1
  • Color gamut: 110% P3
  • Refresh Rate: up to 90Hz
  • Response time: <0.1 ms
• Sensor Light: Ambient light sensor
• Dedicates Bluetooth 5.3 antenna
• Wi-Fi: Tri-band Wi-Fi 6E radio, 2.4GHz, 5GHz, and 6GHz 2 x 2 MIMO, IEEE 802.11a/b/g/n/ac/ax
• Audio Channels: Stereo with embedded DSP
• Dual microphone array
• Headphone / mic jack: 3.5mm Stereo
• Multichannel Digital audio via DisplayPort over USB-C, standard USB-C, or Bluetooth 5.3
• Power input: PD3.0 Type C power supply, 45W
  2.5m cable
• Battery: 50Whr battery. 3-12 hours of gameplay
• MicroSD expansion: UHS-I supports SD, SDXC and SDHC
• External connectivity (displays/controller): Display port over Type C; up to 8K @60Hz or 4K @120Hz, USB3 gen 2
• Size: 298mm x 117mm x 49mm
• Weight: Approx. 640 grams
• OS: SteamOS 3 (Arch Based)
• Desktop: KDE Plasma

Item Specifics

Barcode: 814585022537
Manufacturer: Valve
Weight (Packaged): 1.57 kg
